Product

General
Dimension 850(W) x 1330(H) x 500(D)(mm)
Weight 120 Kg
Weight including accessories 127 Kg
Main voltage 220/230V, 50/60Hz
Maximum power consumption 2990 VA
Main current 12A
Safety class Class 4 laser according to EN60825-1

Laser System
Laser type Long pulsed Nd:YAG Laser and ALEXANDRITE Laser
Wavelength 1064nm and 755nm
Beam delivery system   Via optical fiber ∅ 1000µm x 3m
Aiming beam 532nm, 5mW
Maximum energy Up to 100J for Nd:YAG, up to 60J for ALEXANDRITE
Maximum pulse fluence Max 600J/cm²
Pulse width 0.2 – 350 ms
Frequency 0.4 – 10.0Hz
Beam mode quality Top Hat Mode
Skin cooling type Spray cooling or Air cryo cooling
Laser cooling Water-to-air heat exchanger
Pulse Control Finger, Foot switch, Wireless Foot switch
Calibration Auto-calibration through external port
spot size Ø 2,4,6,8,10,12,16,20 mm (Auto-Detected)
Display System 10.4” Touch LCD GUI
Memory Slot 420 slot
