General

Demension:         320(W) x 830(D) x 1010(H) (mm)
               (Include Arm H : 1620 mm)

Weight:           87.5 Kg

Weight including accessories: 96 Kg

Main voltage:         220/230V, 50/60Hz

Maximum power consumtion:  3000 VA

Main current:         12A

Safety class:            Class IV laser

Laser System

Lasert type:        Q-Switched Nd:YAG

Wavelength:          1064nm / 532nm

Beam delivery system:       Via 7-articulated arm

Aiming beam:        635nm, 5mW

Energy(@Head Aperture):    Up to 2200mJ @ 1064nm PTP Q-Switched
               Up to 600mJ @ 532nm PTP Q-Switched
               Up to 1200mJ @ 1064nm Q-Switched
               Up to 500mJ @ 532nm Q-Switched
               Up to 3400mJ @ 1064nm Quasi-Long

Pulse width:        5~7ns @ 1064nm Q-Switched
              5~7ns @ 532nm Q-Switched
             ~20ns @ 1064nm PTP Q-Switched
             ~20ns @ 532nm PTP Q-Switched
             300㎲ @ 1064nm Quasi-Long

Frequency:        Up to 25Hz @ 1064nm Q-Switched
             Up to 15Hz @ 532nm Q-Switched
             Up to 15Hz @ 1064nm PTP Q-Switched
             Up to 15Hz @ 532nm PTP Q-Switched
             Up to 25Hz @ 1064nm Quasi-Long

Laser cooling:         Water-to-air heat exchanger

Beam mode quality:    Top Hat Mode

Spot size (*Optional)

Zoom Handpiece:       1064nm (Ø 1.5, 2, 3, 4, 5, 6, 7.5, 9,10)mm
               532nm (Ø 1, 1.5, 2.5, 3.5, 4.5, 5.5, 7, 8.5, 9.5)mm

*1064nm Fractional Handpiece: 6 x 6 mm², 9 x 9 dots, Up to 5.2J/cm²

*532nm Fractional Handpiece:   6 x 6 mm², 9 x 9 dots, Up to 1.3J/cm²
