Product

General

Demension:         320(W) x 420(D) x 1100(H) (mm)
              (Include Arm H: 1840mm)

Weight:           38 Kg

Weight including accessories: 45.3 Kg

Main voltage:        200/240V, 50/60Hz

Maximum power consumtion: 400 VA

Safety class:        Class IV laser

Laser System

Laser type:      Fractional CO₂ laser, Scanner type

Laser mode:      Ultra pulse, Super pulse, CW

Wavelength:      10.57 ~ 10.63 ㎛, invisible infrared

Beam mode quality:  TEMㆀ, 95% purity

Beam quality (at 1/e²): M²≤ 1.2

Laser power output:  Up to 30W

Adjustable spot size:   120 / 300 / 600 ㎛

Spot:         size70 ㎛, 49 pixel (10 × 10 mm)

Delivery system:    7-joint, fixed mirror articulated arm

Cooling system:    Water

Scanner system

Scanning area:     X : 3 ~ 20 mm, Y : 3 ~ 20 mm

Scanning shape:    Rectangle, Circle, Diamond, Hexagon, Round rectangle

Scanning direction:   Sequence, Converge, Diverge, Smart Random, Spray

Dot pitch (Density):   0.5 ~ 1.9 mm

Pulse width:      Typically 360 ~ 10,000 ㎲

Energy in one dot:    Typically 5.4 ~ 150mJ (@16 Watt, 1 time)

Overlap:         1 ~ 9 times

Surgical system

Ultra Pulse:      Pulse width 400 ~ 1,250 ㎲
           Exposure time 10 ~ 1,000 ㎳
           Repeat delay 10 ~ 1,000 ㎳ / Single
           Power peak 7.0 ~ 20.0 Watt

Super Pulse:     Exposure time 500 ~ 9,000 ㎲

           Repeat delay 10 ~ 1,000 ㎳ / Single
           Power 10.0 ~30.0 Watt

Continuous Wave:   Power 0.5 ~ 30.0 Watts
