Product

General

Demension:         320(W) x 710(D) x 1000(H) (mm)
               (Include Arm H: 1610mm)

Weight:           55 Kg

Weight including accessories:  57.2 Kg

Main voltage:         200/240V, 50/60Hz

Maximum power consumption:  330 VA

Safety class:          Class IV laser

Laser System

Laser type:       fractional CO₂ laser, RF driver type

Laser modeStamp:    Spray, Ultra pulse, CW

Wavelength:      10.57 ~ 10.63 ㎛, invisible infrared

Beam mode quality:     TEM00, 95% purity

Beam quality (at 1/e²):  M²≤ 1.2

Laser peak power:     75W

Laser Average power:  30W

Spot size:        70 ㎛, 49 pixel (10 × 10 mm)

Delivery system:     7-joint, fixed mirror articulated arm

Cooling system:        Air

Surgical system

SUI / VR Mode & Fracional STAMP Mode:    Power 5.0 ~ 30.0 W
                        On 10 ~ 1000 ms
                        Off 10 ~ 3000 ms, Single

Surgical – Ultra Pulse:              Power 5.0 ~ 30.0 W
                        Pulse Width 400 ~ 1250 ㎲
                       On 10 ~ 1000 ms

                       Off 10 ~ 3000 ms, Single

Surgical – Continuous Wave:           Power 0.5 ~ 30 W
